JHZH Series Double Spiral Conical Mixer

JHZH series asymmetric double helix conical mixer is a new type of mixing equipment with high efficiency and high precision. The machine uses a set of motor and cycloidal pinwheel reducer to revolution and rotation, the use of long and short stirring screw rotation movement and two screw rotation movement of the principle of integration, so that the proportion of different materials to achieve the ideal mixing, mixing time is short, the effect is good.

Get a free quote

JHZH Series Double Spiral Conical Mixer

How it works

Due to the revolution of the double helix, the powder moves in a circle along the cone wall. The rotation of the spiral blade causes the powder to discharge to the center of the cone for radial motion. The powder flows upward from the cone and is discharged on the surface of the outer circumference of the spiral, that is, mixing in the direction of the spiral axis. The combination of spiral revolution and rotation in the mixer results in four flow forms of the powder, that is, the composite movement of convection, shear, diffusion and infiltration. Therefore, the powder material can quickly achieve uniform mixing in this mixer.

Equipment advantages

01 Advanced Structure

Advanced structure, easy operation, safe and reliable operation, spiral shaft without bottom bearing, it removes the failure caused by the bottom bearing leakage powder.
02 Double Helix Asymmetric Arrangement

The mixing speed is fast, the mixing quality is uniform. The double helix of the machine is asymmetrically arranged, and one large and one small expand the mixing range, so it is more suitable for the mixing of different specific gravity and special mixing ratio. Short mixing time, high mixing uniformity, clean discharge.
03 Energy Saving

The energy saving effect is remarkable, the energy consumption of the machine is only about one-tenth compared with the drum mixer.
04 Mild Mixing Process

The mixing process is mild, the material will not produce pressure feed, wear, overheating phenomenon.
05 Stable Formulation

The mixed preparation is stable without stratification and segregation.
06 Support Customization

Sealed dust-free, simple operation, easy maintenance. Long service life, according to user requirements, the cone can be made into a pressure vessel for pressure and vacuum operation.

Technical Parameters

JHZH series double helix cone mixer selection parameters
model	JHZH-0.5	JHZH-1.0	JHZH-1.5	JHZH-2	JHZH-3	JHZH-4	JHZH-5	JHZH-6	JHZH-8	JHZH-10	JHZH-15	JHZH-20
Nominal volume(m³)	0.5	1	1.5	2	3	4	5	6	8	10	15	20
Filling coefficient%	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6	0.6
mixing uniformity	relative deviation＜1.5% 15min
mixing time（min)	5-20min
Particle size range(mesh)	20-1250
power(kw)	3	4	5.5	5.5	7.5	11	15	15	18.5	22	37	45
notes	Customizable non-standard volume Customizable jacket heating and cooling functions Customizable online weighing and measuring function
