GXJ Continuous Powder Coating Modification Machine
GXJ-300 continuous powder surface modification machine is composed of raw material bin, reagent barrel, feed screw, reagent metering and filling system, modification machine host, cyclone collector, pulse dust collector, induced draft fan, electric control system and so on.
The unique modified cavity design and self-heating heating mechanism of the machine meet the continuous modification process requirements of the powder surface, with strong continuity, high coating efficiency, high activation index, large processing capacity and so on. The high-speed friction and shear between the stator and the stator have the function of depolymerization and dispersion of the material at the same time. Since it was introduced to the market, the equipment has been tested by a number of cooperative manufacturers and has been praised and affirmed by the majority of users.
Air mixer is mainly used in chemical products, plastics, pharmaceuticals, battery materials, food, feed, cement, earth and stone, ceramic raw materials and other industries. It is a non-destructive particle and powder mixing equipment, it has no leakage, no dead Angle, no pollution, sealed mixed environmental protection characteristics. Low maintenance cost, fast mixing speed, especially suitable for fast and uniform mixing of large quantities of materials.
Technological Process
1. Feeding system 2. Modify the main machine 3. Cyclone collector 4. Dust collector 5. Induced draft fan
- 01 Good DispersibilityGood dispersion of powder and surface modifier, uniform coating of particle surface, less amount of modifier per unit product; Especially suitable for surface modification of ultrafine powder.
- 02 Large Processing CapacityThe unit can run continuously, large capacity, suitable for various scale of industrial production.
- 03 Low Energy ConsumptionThe use of modified agents is high, the amount is small, the powder coating rate and activation index are high, and the energy consumption is low.
- 04 Using Multiple MaterialsThe equipment has both modification and dispersion functions, suitable for a variety of fineness of materials, small pseudo-specific gravity, bulk density ratio of materials such as white carbon black, mica powder, talc powder and other unique modification and activation effect.
- 05 High Modification EfficiencyPowder and pharmaceutical high-speed gas-solid eddy current mixing operation, high modification efficiency, basically does not damage the original particle shape of the powder.
- 06 EnvironmentallyMaterial negative pressure operation, good sealing, dust does not leak, basically pollution-free, good operating environment, low labor intensity.
- 07 System StabilityIndependent fluid, non-fluid dosing system, continuous stable and uniform.
Model | Main machine power | Capacity | Feed water | Blowe power |
（kw） | (kg/h) | (%) | (kw) | |
GXJ200 | 16.5 | 30-80 | ≤0.5 | 4 |
GXJ300 | 55.5 | 300-2000 | ≤0.5 | 7.5 |
GXJ600 | 111 | 1800-4000 | ≤0.5 | 30 |
GXJ900 | 225 | 3500-8000 | ≤0.5 | 55 |
0536-6946786 -
Book an experiment -
Logistics and transportation -
Host Smash -
Instrument detection -
Experimental analysis -
Configuration selection
-
A company in Changzhou
Material Name：Light calcium carbonateDischarge fineness：325 mesh -
A company in Shandong
Material Name：Aluminium oxideDischarge fineness：325 mesh -
A company in Shandong
Material Name：Ammonium polyphosphateDischarge fineness：20μm -
A company in Zhejiang
Material Name：Iron oxide redDischarge fineness：325 mesh, sieve residue < 0.1% -
A company in Qingdao
Material Name：Expanded graphiteDischarge fineness：D50:4-5μm -
A company in Daqing
Material Name：Honeycomb catalystDischarge fineness：800目800 mesh
